Turbine Test Tank

Turbine Test Tank

The Laminar flow test tank will be 10′ x 20′ x 5’deep with an over tank work platform and a 30″ x 60″ viewing window in the side. The test tank will be built from a steel square tube frame lined with multiple layers of marine plywood and coated with a liquid rubber membrane. After pricing a number of “prebuilt” test tanks, we decided to build our own tank to conform to our limited budget. The water flow in the tank is generated by four 5hp pumps arranged to turn half of the tank into a eductor, so we can use a small fast flow of water to circulate a large volume of water in the tank. Once again, the improvised eductor arrangement was decided on to fit the budget. The tank will be built where it can be transported by Semi truck, and when we have completed using it for testing, we will donate it to a local university.
